Ceramic Multifiber ferrule (CMF®)
Ceramic multifiber ferrule for PC connection
-
FEATURES
-
- Heat resistant
- Hole design flexibility
- Diverse optical connection variations (also available for EB connector applications)
- Width and height can be customized
- Supports ultra-Multifiber of 36-Fiber or more
-
APPLICATION
-
- Co-Packaged Optics (CPO)
- On Board Optics (OBO)
-
SPECIFICATIONS
-
Brand CMF®
Fiber Type Single-Mode / Multi-Mode
Grade Standard Loss <0.70dB(SM)/<0.50(MM) Super Low Loss <0.35dB (SM/MM) Fiber Count customizable
Endface Type Flat
Polish Type PC and APC
Fiber Cladding Size 80/125µm
Fiber Pitch 125/127/250µm
Remarks - The fiber protrusion can be polished, making it possible to connect to a PC.
- We will provide you with detailed information on the conditions and methods for polishing.
