MTCOMPACT ® Slim & Short

High-density mounting through miniaturization of multifiber optical connector

MTCOMPACT ® Slim & Short
MTCOMPACT ® Slim & Short
MTCOMPACT ® Slim & Short
MTCOMPACT ® Slim & Short

FEATURES

  • 1/4 the size of the standard product (length 4.0 mm / thickness 1.25 mm)
  • Supports Single-mode / Multimode
  • Dedicated guide pins/clips can also be supplied.
  • Dedicated connector housing under development
  • Ideal for space-saving designs in optical devices
  • Contributes to miniaturization of optical connection structures

APPLICATION

  • MT harness (for optical transceivers)
    *Use in conjunction with plastic lenses

SPECIFICATIONS

Brand

MTCOMPACT®

Fiber Type

Single-Mode / Multi-Mode

Grade
Standard Loss <0.70dB(SM)/<0.50(MM)
Fiber Count

1×12-16

Endface Type

Flat

Polish Type

PC and APC

Fiber Cladding Size

125µm

Fiber Pitch

250µm

Remarks
  • Insertion Loss is based on random connection (all channels 97% or more). *IEC61755-1.
  • A dedicated polishing jig is required (information about polishing jigs can also be shared).

*If the table cannot be displayed in its entirety, please scroll horizontally to view it.
